Installation & Structural Considerations for Water Tanks
A correctly specified tank can fail if installation quality is poor. This article addresses the practical engineering considerations – access logistics, structural support, base preparation, and assembly quality – that determine whether a tank starts its service life in a safe, compliant condition.
M&E consultants · Specifiers · Facilities managers · Asset owners
Water Supply (Water Fittings) Regulations 1999; ACoP L8; HSG274 Pt 2; BS EN 13280; BS EN 12845
Approx. 12 minutes
Planning Tank Delivery and Access
Before a tank or its panels arrive on site, a detailed access survey must cover every point on the delivery route: doorway widths, staircases, elevators, corridor turns, ceiling heights, and any crane access points.
- One-piece tanks must physically fit through all openings. If a large one-piece tank cannot pass through the narrowest constraint, either a smaller one-piece must be selected, a sectional tank specified instead, or temporary structural modifications (partial wall removal, roof cranage) planned and costed.
- Sectional GRP panels can pass through doorways of 750 mm minimum clear width. All doorways, stairwells, corridors, and lifts on the delivery route must be surveyed and confirmed before specifying panel dimensions. A tank that cannot be delivered to the plant room in its required configuration cannot be installed.
- The tank top must also accommodate the access provisions required for confined space entry — manway clearance, tripod rescue system height, and platform space.
oN-SITE HANDLING
Identify requirements for forklifts, pallet jacks, or hoists to move panels from delivery point to installation location. Schedule sufficient manpower — GRP panels are lightweight but still require two people to carry safely. Safety considerations for crew working at height or in confined spaces should be integrated into the method statement.
Structural Loading and Floor Loading Implications
Water weighs 1 kg per litre (1,000 kg per m³). A fully charged 10,000 L tank exerts 10 tonnes of load on the plant room floor, distributed over the tank base footprint.
Structural assessment of the floor is required for any tank above approximately 5,000 L in an existing building, and should be confirmed at design stage for new builds. Distributed loading across the tank base does not eliminate the need for a structural check – slab capacity and point load at supports must both be assessed.
CONSEQUENCE OF NON-COMPLIANCE
BASE SUPPORT REQUIREMENTS
For EFB sectional tanks, the support system typically comprises parallel concrete plinths or rolled steel joists (RSJs) at 1,000 mm centres for metric panels or 1,220 mm centres for imperial panels. The supports should run in one direction only and must be at least 300 mm longer than the overall length of the tank to support the external vertical flanges.
INSTALLATION REQUIREMENT
FINAL BASE SUPPORT SYSTEM
The final base support system must be flat, level, and strong enough to support the weight of the tank when full without movement. For IFB or TIF tanks placed on a solid slab, the slab must be reinforced to bear the full water load plus the self-weight of the tank.
Base Preparation and Levelness Tolerances
A level base is fundamental for the structural integrity of a water tank. An uneven foundation causes stress on the tank walls, leading to cracks and leaks over time. Industry-standard tolerances for sectional tank bases are:
- 2 mm in any metre
- 6 mm in any 6 metres
Maximum beam deflection 1:500
Achieving these tolerances requires precision during construction. Use a laser level to verify flatness before tank assembly. Where steel beams are used, shims or self-levelling grout may be needed to bring supports within tolerance.
BASE MATERIALS
Use durable, water-resistant materials that can withstand the tank’s weight and environmental conditions. Using materials like chipboard instead of marine-grade plywood can result in moisture absorption, leading to base degradation and potential tank failure. Always opt for materials specified by the tank manufacturer — typically concrete plinths, steel beams, or marine-grade board.
FINAL NOTE
Clean the base of any local debris or other items before placing the tank, as foreign objects can create pressure points and damage the tank base over time.
Common Installation Mistakes and How to Avoid Them
The following nine failure modes are regularly encountered in water tank installations:
Uneven Base Installation
A level base is fundamental. An uneven foundation causes stress on tank walls, leading to cracks and leaks.
fix
Ensure the base is constructed using appropriate materials like base levelling steels and is perfectly level before installation.
Using Inappropriate Base Materials
Using chipboard instead of marine-grade plywood can result in moisture absorption, leading to base degradation and tank failure.
fix
Always opt for durable, water-resistant materials.
Oversized Tanks Leading to Stagnation
An oversized tank leads to water stagnation due to insufficient turnover. Stagnant water becomes a breeding ground for bacteria, including Legionella, posing health risks and compliance issues.
fix
Assess facility water usage accurately to determine the appropriate tank size.
Inadequate Access for Maintenance
Installing tanks in locations with limited access hinders routine inspections, cleaning, and maintenance, leading to neglected upkeep and potential system failures.
fix
Ensure the tank’s placement allows for easy and safe access for personnel.
Improper Bolt Tightening
Bolts not adequately tightened during installation can loosen over time, leading to leaks and structural instability.
fix
Follow manufacturer specifications for bolt torque and recheck tightness after the tank has been filled and settled.
Using Non-Marine-Grade Bolts and Washers
Standard bolts and washers instead of marine-grade options lead to rapid corrosion, especially in humid environments. Corroded fittings compromise the tank’s integrity.
fix
Always use corrosion-resistant, marine-grade hardware.
Inadequate or Poorly Installed Seals
Low-quality sealants or improper installation techniques result in seal failure.
fix
Ensure that high-quality, WRAS-approved sealants are used and that installation follows best practices to maintain watertight integrity.
Neglecting Tie Bar Tension
Tie bars are essential for maintaining structural integrity of sectional water tanks. If not properly tensioned, tank walls can bow or flex when filled, leading to joint stress and potential leaks.
fix
Regularly check and adjust tie bar tension as part of installation and maintenance.
Using Non-WRAS Approved Materials
Materials that are not WRAS approved can lead to compliance issues and potential contamination of the water supply.
fix
Ensure all materials, including sealants, coatings, and fittings, meet WRAS standards.
Pre-installation recommendation
Run this list past the chosen contractor and ask them to verify their plans in respect to each point, providing confidence that the installation will not suffer from one or more of these issues.
Frequently asked questions
What should be checked before installing a water storage tank?
Before installing a water storage tank, the full delivery route should be checked, including doorway widths, staircases, corridors, lifts, ceiling heights, and crane access points.
The installation area should also be reviewed for structural loading, floor strength, base levelness, support design, maintenance access, and safe working requirements. These checks help confirm that the tank can be delivered, positioned, filled, maintained, and operated safely.
Why is structural loading important when installing a water tank?
Structural loading is important because water is heavy. A full water tank places a significant load on the floor, support beams, plinths, or slab beneath it.
As a simple guide, water weighs 1 kg per litre, so a 10,000-litre water tank holds approximately 10 tonnes of water before allowing for the weight of the tank itself. The floor structure should therefore be assessed before installation, especially for larger tanks or installations in existing buildings.
What base is required for a sectional water tank?
A sectional water tank requires a flat, level, and load-bearing base that can support the full tank weight when filled. Depending on the tank type, this may involve concrete plinths, rolled steel joists, a reinforced slab, or another manufacturer-approved support system.
Base levelness is critical. An uneven base can place stress on the tank panels, joints, seals, and fixings, increasing the risk of leaks, panel distortion, or premature failure.
What are the most common water tank installation mistakes?
Common water tank installation mistakes include poor access planning, uneven base preparation, incorrect support spacing, inadequate maintenance clearance, poor bolt tightening, unsuitable fixings, low-quality seals, and the use of non-approved materials.
These issues can lead to leaks, structural movement, corrosion, hygiene risks, or early tank failure. A pre-installation review with the contractor can help confirm that access, base preparation, structural support, and assembly requirements have been properly planned.
How much access space is needed around a water storage tank?
Access space depends on the tank type, base configuration, and maintenance requirements, but the tank should always be installed with enough clearance for inspection, cleaning, valve access, and safe future servicing.
For sectional tanks, access planning is especially important. EFB tanks usually require clearance around the tank and below the base for external flange assembly, while IFB and TIF tanks can be better suited to restricted spaces. The required access should be confirmed with the tank manufacturer before the plant room layout is finalised.
