Cold Water Storage Tanks for Flats, Apartments and Residential Buildings
Most blocks of flats in the UK do not run every tap straight off the incoming main. Water is taken into a communal cold water storage tank, then lifted through the building by a booster set and distributed up the risers to each apartment. The tank sits at the centre of that arrangement: it sets the capacity available to residents, it is the point at which water hygiene is won or lost, and it is usually the oldest component in the plant room.
Tricel supplies sectional and one-piece GRP cold water storage tanks for residential buildings of every height — purpose-built blocks of flats, converted buildings, mixed-use developments with apartments above retail, student accommodation, HMOs, and retirement and extra-care housing. Panels pass through a standard 750mm doorway, so a tank can be replaced in an occupied building without craneage or structural opening-up in most cases.
Key facts at a glance
750mm
Sectional GRP panels can pass through a standard doorway, helping with replacement in restricted-access residential plant rooms.
25–30 yrs
Tricel design-life guidance for correctly installed and maintained GRP water storage tanks.
Twin-compartment
Allows one section to remain in service while the other is isolated for cleaning, maintenance or replacement.
<20°C
Cold water should be stored below 20°C as part of Legionella risk control in communal systems.
3 options
Typical occupied-building changeover routes: compartment-by-compartment, temporary tank and pump, or a planned shutdown.
BS EN 13280
Relevant product standard for GRP cisterns and sectional water storage tanks.
01
Residential Applications
Where cold water storage is used in residential buildings
The supply arrangement follows from the building, not from its use class. The pattern below is typical rather than prescriptive; the incoming main’s pressure and flow at your site decides the outcome.
|
Building type
|
Typical supply arrangement
|
Storage implication
|
|---|---|---|
|
House or maisonette, mains pressure adequate
|
Direct mains to all outlets
|
No storage, or a small feed cistern for a vented hot water system
|
|
Older house with a vented system
|
Loft cistern feeding hot water cylinder and some cold outlets
|
One-piece cistern, replaced on refurbishment or when the cylinder is changed
|
|
Low-rise block, 2–4 storeys
|
Often direct mains, sometimes a small break tank and pump set
|
Modest communal storage where mains pressure will not reach the top floor
|
|
Mid-rise block, roughly 5–8 storeys
|
Break tank and booster set almost always required
|
Communal sectional tank in a ground-floor or basement plant room
|
|
Taller residential block
|
Break tank, booster set and pressure-zoned risers
|
Larger communal storage, commonly in two compartments
|
|
Student accommodation and HMOs
|
Break tank and booster set, sized for sharp peak demand
|
Storage sized for concentrated morning and evening draw-off
|
|
Retirement and extra-care housing
|
Break tank and booster set with resilience priority
|
Two compartments so one side can be isolated without loss of supply
|
02
Water storage systems
Cold water storage for blocks of flats and apartment buildings
Three components do the work in a boosted residential building, and it is worth being clear about what each one is for.
System Components
The break tank
A break tank is an open, vented cistern that breaks the physical continuity between the public main and the building’s pumped system. That break does two things. It protects the main from backflow out of the building, which is why the inlet is fitted with an air gap rather than a mechanical valve. And it gives the booster pumps a reservoir to draw from, so they are not pulling directly on the main and reducing pressure for neighbouring properties. Water undertakers generally require the break for this reason. Hydraulic design and pump selection are set out in the break tank and booster set design guide; for smaller blocks, see Category 5 break tanks.
System Components
The booster set
The booster set takes water from the tank and delivers it up the building at a controlled pressure. It is normally a duty-and-standby or multi-pump arrangement with variable speed control, so that pressure at the top-floor taps stays usable when demand changes. The pumps are the part residents notice: if the tank is undersized or silted, the pumps cycle, and the symptoms reach the managing agent as complaints about pressure.
System Components
The riser
The riser is the vertical distribution pipework carrying boosted cold water to each flat. In taller blocks it is split into pressure zones, each served by its own branch from the booster set or through pressure-reducing valves, so that lower floors are not exposed to the pressure needed at the top. Zoning decisions belong with the M&E designer; they are set out in our reference on pressure zoning in high-rise buildings.
03
Replacement Triggers
When a residential cold water tank needs replacing
Tanks are rarely replaced on age alone. Replacement is usually triggered by one of the following, and the trigger shapes the programme.
Tank Replacement
Leaks and joint failure
Sectional tanks leak at the joints, not through the panels. The usual cause is base movement or a base that was never level within tolerance, which loads the joints unevenly over time. A weeping joint in a plant room above occupied flats is a water damage risk and an insurance conversation, and in a tank that has been repeatedly re-sealed it is normally a sign that replacement is due rather than repair.
Tank Replacement
A failed Legionella sample or an adverse risk assessment
A positive Legionella result, or a risk assessment that records a tank as beyond effective cleaning, forces a decision. Internal corrosion, failed or absent insulation, a damaged lid, missing insect screens, heavy sediment or a tank that cannot be isolated for cleaning are all findings that point to replacement rather than another clean. The written scheme should record the decision and the interim controls applied while replacement is planned.
Tank Replacement
Loss of usable capacity
Stored capacity is lost slowly and invisibly. Sediment reduces the working volume, a float valve set low reduces it further, and a tank that was sized for the building’s original occupancy may no longer suit it after a loft conversion, an extension of the block, or a change from family occupancy to sharers. Complaints about morning pressure on upper floors are often a capacity problem presented as a pump problem.
Tank Replacement
Galvanised steel and early GRP tanks reaching end of life
Galvanised steel tanks corrode from the inside and are common in blocks built or refitted before the widespread adoption of GRP. Early GRP tanks may predate current certification for contact with drinking water, or may have insulation and lid arrangements that no longer meet what a risk assessor expects to see. Tricel gives correctly installed and maintained GRP tanks a design life of 25 to 30 years; a tank at or beyond that point should be on a planned replacement programme rather than a reactive one. See cold water storage tank replacement.
Tank Replacement
Recladding and building safety remediation
External wall remediation projects can provide a valuable opportunity to assess and upgrade ageing building services alongside façade works. At this stage, access equipment such as scaffolding or hoists is often already in place, a principal contractor has been appointed, residents have been notified of planned works, and funding may already have been allocated to the wider improvement programme. Considering cold water storage replacement during these works can help reduce overall project disruption, improve coordination between contractors and potentially avoid the need for separate access and mobilisation costs at a later date.
There may also be a strong asset management and compliance case for reviewing existing cold water storage. Older galvanised steel tanks or early-generation GRP tanks may be reaching the end of their service life and could benefit from refurbishment or replacement as part of a broader building improvement strategy. If your building is undergoing external wall remediation, it is worth discussing the condition and future suitability of the cold water storage system during the design and planning stages, rather than after access equipment has been removed.
Consider the following actions during project planning:
- Request that the M&E consultant includes a condition survey of the cold water storage system as part of the pre-construction assessment.
- Confirm whether access routes to plant rooms or tank locations may be affected by the remediation works and plan delivery and installation activities accordingly.
- Review whether any temporary water supply arrangements required during remediation works could also support a future tank replacement programme.
This approach can help building owners and managers align essential asset renewal with planned capital works, reducing disruption to residents while supporting the long-term performance of the building.
04
Occupied Buildings
Replacing a tank in an occupied building
The engineering is the straightforward part. The constraint in residential work is that people live in the building and expect water at the tap.
Occupied Tanks
Getting the tank in without craneage
Sectional GRP panels are sized to pass through a standard 750mm doorway and can be carried up a stairwell or through a corridor by hand. For a plant room in a basement or ground floor with no external access, this is usually the only practical route, and it avoids road closures, crane permits and the loss of resident parking that a one-piece delivery would require. A pre-delivery access survey measuring every doorway, turn and stairwell on the route is the step that prevents a delivery day failure.
Occupied Tanks
Residents, notice and working hours
Give residents written notice of any interruption with the date, the window, what will and will not work, and a named contact. Where a building has residents with medical or mobility needs, identify them in advance and agree arrangements with them individually rather than relying on a general notice. Check the lease and any local authority condition for permitted working hours before committing to an overnight changeover, and confirm what noise the works will make in flats adjoining the plant room.
Occupied Tanks
Temporary supply and phasing
There are three common approaches, and the choice usually comes down to the plant room layout.
- Compartment-by-compartment. Where the existing tank has two compartments, one side is isolated and replaced while the other maintains supply. This is the least disruptive option and is one reason to specify two compartments on replacement even where a single compartment would meet the volume requirement.
- Temporary tank and pump. A temporary storage and boosting arrangement is set up alongside, supply is switched, the old tank is removed and the new one built and commissioned. This adds cost and needs space, but it keeps water on throughout.
- Planned shutdown. Where the building can accept it, supply is taken off for a defined window — often overnight or across a weekend — with the changeover, chlorination and sampling programmed into it. This is the cheapest route and the one that needs the most resident communication.
Whichever route is chosen, the new installation is chlorinated, flushed and sampled before it is brought into service, and the results form part of the handover record. See the guide to chlorination and commissioning.
05
Ownership & responsibility
Who is responsible for the water tank in a block of flats
Responsibility follows the tenure and the lease, and it is worth establishing in writing before work is commissioned.
|
Party
|
Typical position
|
|---|---|
|
Freeholder
|
Owns the structure and, in most leases, the communal plant. Usually the party with the repairing obligation for the tank and the plant room.
|
|
Resident management company or right-to-manage company
|
Where leaseholders have taken over management, the company carries the repairing obligation and the health and safety duties that go with the communal system.
|
|
Managing agent
|
Acts for the freeholder or the RMC. Commissions the risk assessment, holds the records, instructs contractors and runs the consultation. Duties remain with the client, but the agent is normally the accountable point in practice.
|
|
Housing association or local authority
|
Landlord of the communal system, with the same duties plus its own regulatory and tenant-consultation regime.
|
|
Principal Accountable Person
|
In an occupied higher-risk building in England — at least 18 metres in height or at least seven storeys, with two or more residential units — the Building Safety Act 2022 places a separate dutyholder regime on top of the duties above. It does not displace them.
|
|
Individual leaseholder
|
Normally responsible only inside the demise, for example a cylinder or a cistern within the flat. The communal tank is not usually a leaseholder repair.
|
Note
The Building Safety Act regime is set out in more detail on our high-rise page.
06
Water Hygiene
Water hygiene duties in residential buildings
A communal cold water system in a block of flats is a water system operated in connection with an undertaking, so it falls within the general duties in the Health and Safety at Work etc. Act 1974 and the Control of Substances Hazardous to Health Regulations 2002, with HSE’s Approved Code of Practice L8 and the guidance in HSG274 Part 2 setting out what is expected. In practice that means a written Legionella risk assessment for the communal system, a written scheme of control, a named responsible person, monitoring records, and cleaning and disinfection at a frequency the risk assessment sets — annually as a baseline.
For the tank itself, the controls that matter most are cold water stored below 20 °C, a close-fitting and screened lid, intact insulation, turnover fast enough to prevent stagnation, and access sufficient to inspect and clean the interior. HSE takes a lighter view of the systems inside individual domestic tenancies than of communal plant; the communal tank is the part that attracts scrutiny. Our Legionella risk assessment guide covers the method, and the cleaning and chlorination guide covers the routine.
07
Specification
Notification, certification and what to put in a specification
Four points cover most residential procurement.
Notify the water undertaker
Under the Water Supply (Water Fittings) Regulations 1999, the extension or alteration of a water system on premises other than a house is notifiable, and consent should be in place before work starts. A block of flats is not a house for this purpose. Devolved equivalents apply in Scotland and Northern Ireland.
Specify to the product standard
BS EN 13280 is the relevant standard for GRP cisterns and sectional tanks. Name it in the specification.
Require certified materials
Ask for evidence that the tank materials are approved for contact with drinking water — WRAS approval or Kiwa KUKreg4 certification, tested to BS 6920 — and verify the certificate is current rather than accepting a reference to it.
Specify two compartments where continuity matters
For any residential building where losing supply creates a welfare problem, or where the tank cannot be taken out of service for cleaning without a shutdown, two compartments are the practical answer.
Note
Sizing, stratification control and installation tolerances are covered under specification, standards and design life on the high-rise and multi-storey reference.
08
Project Planning
Cost, service charges and leaseholder consultation
A communal tank replacement is normally recoverable through the service charge as a qualifying work, which brings a consultation requirement with it. Under section 20 of the Landlord and Tenant Act 1985, as amended, a landlord in England or Wales must follow the statutory consultation procedure for qualifying works where any single leaseholder’s contribution would exceed the threshold set by regulations. Failing to consult can leave the cost irrecoverable, so the consultation timetable should be built into the programme from the outset rather than added once a contractor has been chosen.
Two points follow from that. First, a tank replacement is much easier to fund from a reserve or sinking fund than from a one-off demand, which is an argument for putting it on a planned programme once a tank passes 20 years. Second, where remediation or major works are already being consulted on, including the tank in that consultation is simpler than running a second one later.
General information, not legal advice. Consultation requirements and cost recovery depend on the terms of the individual leases and on current regulations. Take your own legal advice before relying on this section.
09
Tank Selection
Sectional or one-piece: which suits a residential building
|
Comparison Criteria
|
Sectional GRP tank
|
One-piece GRP cistern
|
|---|---|---|
|
Typical residential use
|
Communal storage in a plant room, basement or roof plant space
|
Loft cistern in a house, feed cistern for a vented system, small break tank
|
|
Access
|
Panels pass a 750mm doorway and can be carried up a stairwell
|
The complete unit must be brought in whole
|
|
Compartments
|
Two compartments available, allowing isolation without loss of supply
|
Single compartment as moulded
|
|
Practical limit
|
No effective upper limit on capacity
|
Suited to smaller volumes
|
|
Replacement in occupied buildings
|
Usually possible without craneage
|
Depends entirely on the access route
|
10
Project support
How Tricel supports residential projects
- Access survey and delivery planning for occupied buildings, including stairwell and corridor routes.
- Sectional and one-piece GRP tanks with materials certified for contact with drinking water.
- Single point of responsibility across supply, installation, levelling steelwork and interconnecting pipework.
- Support on phasing and temporary supply so the programme can be agreed with residents before work starts.
- Documentation for handover and for the building’s written scheme of control.
Case study - Residential Applications
GRP WATER STORAGE FOR FLATS, APARTMENTS, AND RESIDENTIAL BUILDINGS
Tricel Water supplies GRP cold water storage tanks for blocks of flats, apartment buildings, student accommodation, HMOs, and other residential developments across the UK. Sectional tanks suit communal plant rooms and restricted-access locations, with options for phased replacement where continuity of water supply is required.
750mm
Sectional panels can pass through a standard doorway for installation in restricted-access plant rooms.
Common questions
Frequently Asked Questions
Do blocks of flats need a communal cold water storage tank?
Not always. Where the incoming main provides enough pressure and flow to serve every outlet, a block can run directly off the main. Once the building is tall enough that the main will not reach the top floor reliably — commonly around five or six storeys, though it depends on the site — a break tank and booster set is normally required, and the water undertaker will expect the break between the main and the pumps.
Who is responsible for the water tank in a block of flats?
Usually the freeholder, or the resident management company where leaseholders have taken over management, with the managing agent acting for them. The communal tank sits outside the individual flat demise, so it is not normally a leaseholder repair. Check the lease, because the repairing obligation is set there.
How long does a cold water tank in a block of flats last?
Tricel gives correctly installed and maintained GRP tanks a design life of 25 to 30 years. Galvanised steel tanks typically have a shorter service life and corrode internally. A tank approaching 25 years should be on a planned replacement programme rather than left to fail.
Can a tank be replaced without cutting off water to residents?
Often, yes. If the existing tank has two compartments, one side can be isolated and replaced while the other maintains supply. Otherwise a temporary tank and pump arrangement can keep water on, at additional cost. The alternative is a planned shutdown in an agreed window, which is cheaper but needs more notice to residents.
Does a tank replacement need consultation with leaseholders?
If the cost is recoverable through the service charge as a qualifying work and any leaseholder’s contribution exceeds the statutory threshold, the section 20 consultation procedure under the Landlord and Tenant Act 1985 applies in England and Wales. Build the timetable into the programme early; failure to consult can make the cost irrecoverable. This is general information rather than legal advice.
Can a sectional tank be carried into a block of flats through the stairwell?
Yes. Individual panels are sized to pass through a standard 750mm doorway and can be handled up a stairwell or along a corridor. An access survey measuring every doorway, turn and landing on the route should be completed before delivery is booked.
Do we need to tell the water company before replacing a tank in a block of flats?
Yes. Under the Water Supply (Water Fittings) Regulations 1999, altering a water system on premises other than a house is notifiable to the water undertaker, and consent should be obtained before work begins. Scotland and Northern Ireland have their own equivalent requirements.
Is a Legionella risk assessment a legal requirement for a block of flats?
For the communal water system, yes in substance. The duty to assess and control the risk arises under the Health and Safety at Work etc. Act 1974 and the COSHH Regulations 2002, with HSE’s ACoP L8 and HSG274 Part 2 setting out what compliance looks like: a written assessment, a written scheme of control, a named responsible person, and records.
Should we replace the tank while recladding scaffolding is in place?
It is usually the cheapest and least disruptive point at which to do it. Access, a principal contractor, a construction phase plan and resident consultation are already in place. Raise it with the design team during pre-construction rather than after the scaffold is struck.
Do individual flats need their own storage tanks?
Not usually. Modern boosted residential buildings store water communally and distribute it under pressure, so individual flats need no cistern. However, Older flats with vented hot water systems may still have a small cistern within the demise serving the cylinder.
